Maxspect Recurve 120

  • SKU: MAX-R6-120

Effective Coverage: 56in x 26in  |  Maximum Coverage: 60in x 32in
Dimensions: 47.2x 17.5 x 4.6in (LxWxH)   |   Suited for tanks: 48in - 60in


Features
Overview

The Next Evolution of LED Reef Lighting

An aerodynamic body with variable geometry flaps, the Recurve LED Lighting Fixture looks like it could really take flight. The Recurve is an all-in-one LED system utilizing the latest in LED technology, including Cree XT-E and XP-E high intensity LED chips in combination with twin supplimental LED strips both containing 4 seperate supplimenting color channels, offering impressive performance, apearance and ultimate spread in one streamline fixture.

What makes the Recurve unlike any other LED lighting fixture on the maket is its pair of side-mounted flaps fitted with High Output LED Strips which can be angled up to 30° inwards to adjust both light intensity and spread. The High Output LED strips house four independently controllable LED channels that can replicate most popular T5 color blends. Each strip is encased with a special diffuser to further emulate the appearance of T5s but only using LED technology!

Built-in Controller

There’s no need to buy an additional controller just to be able to use your aquarium lighting. The built-in controller integrated in the Recurve features an OLED monitor and a control dial, from which user can easily setup all the functions for the fixture.

Standard or Grouped Mode

2 or more Recurve fixtures can be connected together to control them simultaneously - all grouped fixtures will follow the settings programmed, saving time and effort on setting up multiple fixtures.

Control with iOS or Android Devices (Optional)

The Recurve can be wirelessly connected to a Maxspect Connect ICV6 controller (sold separately), which allows the Recurve fixture(s) to be controlled by iOS or Android devices through the Syna-G app.

MORE DETAILS

R6-090 TECHNICAL SPECIFICATIONS & WARRANTY

Suited for tanks 48in - 60in wide

Dimensions

Length: 47.2in
Width: 17.5in
Height: 4.6in

Power Specifications Consumption

Wattage: 320w
Ballast: Meanwell lrs-350-36
Input: 6.8A/115VAC, 3.4A/220VAC
Output: 36V/9.7A
Weight: 1.23kg

LEDs

Number of Clusters:
Total Number of Cluster LED: 60
Total Number of Strip LED: 360

Colors

LED Cluster - Channel A: Deep Blue

LED Cluster - Channel B: Cool and Warm White

LED Strip - Channel C: Deep Red

LED Strip - Channel D: Cyan

LED Strip - Channel E: Blue

LED Strip - Channel F: Violet + Deep Blue

Channel Led Cluster R6-060 R6-090 R6-120
A Cree XPE-2 470-480nm 6 9 12
Cree XTE Royal Blue 452-455nm 6 9 12
luxeon-c Deep Blue 445-450mm 6 9 12
B Cree XTE Warm White 3000-3500K 4 6 8
Cree XTE Cool White 6500-7000K( 8 12 16
LED Strip R6-060 R6-090 R6-120
C Epiled Deep Red 660nm 36 54 72
D Epiled Cyan 505nm 36 54 72
E Epiled Blue 480nm 36 54 72
F Epiled Violet 405nm 24 36 48
Epiled Violet 415nm 24 36 48
Epiled Deep Blue 440nm 24 36 48

PLEASE NOTE: Fixture must have at least 15 cm (6 inches) of space above the fixture to allow proper heat dissipation. Do not place any foreign object on top of the fixture. Avoid splashing the fixture with water.



12 MONTH WARRANTY

Maxspect (Hong Kong) Limited warrants all Maxspect™ Recurve LED Lighting System products against defects in workmanship for a period of 12-months from the date of purchase. If a defect exists during the warranty period, Maxspect (Hong Kong) Limited at its option will either repair (using new or remanufactured parts) or replace (with a new or remanufactured unit) the product at no charge.

THE WARRANTY WILL NOT APPLY TO THE PRODUCT IF IT HAS BEEN DAMAGED BY MISUSE, ALTERATION, ACCIDENT, IMPROPER HANDLING OR OPERATION, OR IF UNAUTHORIZED REPAIRS ARE ATTEMPTED OR MADE. SOME EXAMPLES OF DAMAGES NOT COVERED BY WARRANTY INCLUDE, BUT ARE NOT LIMITED TO, USING AFTER-MARKET LED BULBS AND MODIFICATION OF THE CIRCUITRY, WHICH ARE PRESUMED TO BE DAMAGES RESULTING FROM MISUSE OR ABUSE.
