Octo Pulse 4 Dry Side Magnet
SKU: ROP-OP4-DSMAG
- Genuine OEM Direct Replacement: Authentic factory-spec external dry side backing magnet engineered explicitly to couple with the Reef Octopus Octo Pulse 4 wavemaker pump system.
- Heavy-Duty Clamping Force: Loaded with dense, industrial-grade rare-earth magnetic cores designed to safely anchor heavy high-output pump bodies through thick glass barriers.
- Premium Soft-Rubber Padding: Features a specialized, non-marring rubberized backing matrix that protects your external aquarium viewing panels from friction scratches.
- Resilient Splash-Proof Enclosure: Fully sealed within a high-impact, non-corrosive polymer shell that shields the core magnets from ambient moisture, humidity, and salt spray.
- Low-Profile Exterior Silhouette: Sleek, low-profile design minimizes the physical protrusion on the outside of your aquarium glass for a clean aesthetic finish.
- Universal Glass Thickness Tracking: Provides an aggressive structural grip across a wide range of standard glass layouts up to 5/8" thick without sliding down the pane.
Reef Octopus
Globally trusted for premium protein skimmers and pumps, engineered in-house for unmatched reef filtration performance.
Reef Octopus Octo Pulse 4 Dry Side Magnet Mount (ROP-OP4-DSMAG)
The Reef Octopus Octo Pulse 4 Dry Side Magnet Mount (SKU: ROP-OP4-DSMAG) is an authentic factory-spec external backing magnet distributed by CoralVue to preserve the secure placement of your high-volume wavemaker assembly. Driving a high-capacity 4,500 GPH circulation pump creates considerable mechanical torque and continuous physical vibrations. If your external backing magnet is dropped on a hard tile floor during a routine equipment overhaul, the impact can fracture the brittle internal rare-earth magnetic discs or crack the protective outer shell. A compromised external magnet cannot provide the clamping force necessary to support your pump, which can cause the internal motor block to slide down your glass pane and stir up your sand bed.
This genuine replacement hardware features a heavy-duty magnetic core enclosed in a durable, impact-resistant polymer casing. The side of the magnet that faces your aquarium is lined with a high-friction, soft-rubber dampening pad. This pad serves a dual purpose: it acts as a protective shield to prevent scratches on your glass or acrylic panels while dampening low-frequency motor hum before it can resonate through your viewing glass.
Key Features
True Factory Tolerance: Sized strictly to mirror the weight balance and magnetic tracking of the internal Octo Pulse 4 wet-side mount.
High-Friction Anti-Slip Pad: The textured rubber backing matrix prevents the pump from slowly drifting down the glass pane over time due to operational vibration.
Moisture-Resistant Casing: Fully enclosed structural shell isolates the internal magnetic material from ambient salt creep and humidity common around open sumps.
Toolless Exterior Alignment: Allows for rapid vertical or horizontal placement changes simply by gliding the external pad across the glass panel.
Verified Hardware Compatibility
Reef Octopus Wavemaker Series: Octo Pulse 4 (OP-4) and Octo Pulse 4+ external mounting configurations.
(Note: This backing magnet is designed explicitly for the high-power clamping demands of the OP-4 platform. If you run the smaller standard model, please source companion part number ROP-OP2-DSMAG to align with your smaller system footprint).
What’s Included:
(1) Reef Octopus Octo Pulse 4 Dry Side Replacement Backing Magnet (Exterior Tank Side Only)
(Note: Submerged wet-side mounting cradles, internal motor stator blocks, impellers, cages, and controllers are sold separately).
Technical Specs:
Official Manufacturing Title: Octo Pulse 4 Dry Side Magnet Mount
SKU / Factory Part Identifier: ROP-OP4-DSMAG
Maximum Rated Glass Thickness: Up to 5/8" (15mm) Structural Paneling
Target Application Placement: Aquarium Display Exterior (Dry Side Only)
Primary System Match: Reef Octopus OP-4 Wave Pump Array
Warranty
CoralVue, Inc. hereby guarantees this product to be free from defects in material and workmanship for a period of:
- 1 Year
Warranty is activated on the date of purchase.
This Standard Limited Warranty applies and is limited as follows:
- To the product only as long as it remains in the possession of the original purchaser.
- To the product that has not been subject to accident, misuse or abuse.
- To the product that has not been modified, altered, defaced, or had repairs made or attempted by other than CoralVue, Inc.
- That CoralVue be immediately notified in writing within ten (10) days of first knowledge of defect by owner or his agent.
- That CoralVue, Inc. shall be given first opportunity to make any repairs, replacements or corrections to the defective construction within a reasonable period of time.
- Under no circumstances shall CoralVue and/or the Manufacturer be liable by virtue of this warranty or otherwise for damage to any person or property whatsoever for any special, indirect, secondary or consequential damages of any nature however arising out of the use or inability to use because of the product defect.
- Turn off your wavemaker controller to cut power to the internal pump before shifting your mounting hardware.
- Securely grip the internal submerged wet-side pump assembly with one hand inside the aquarium to prevent it from dropping.
- With your free hand, slowly slide the old dry-side backing magnet sideways along the exterior glass until the magnetic connection releases.
- Clean the exterior glass surface thoroughly with a microfiber towel to remove any dust, salt film, or fingerprints.
- Place your new ROP-OP4-DSMAG dry side magnet flat against the exterior glass surface, keeping it several inches away from the internal pump's position.
- Slowly slide the new dry magnet toward the internal wet-side mount until you feel the magnetic fields engage and lock the pump firmly in place.
Pro Tips:
- Never Snap the Dry and Wet Magnets Straight Together. Rare-earth backing magnets possess incredible clamping pressure. When matching your new dry-side magnet up with the internal wet-side mount, never point them directly at each other and snap them together. The intense, sudden impact can easily shatter your aquarium glass pane or severely pinch your fingers. Always place the dry magnet on the exterior glass well out of alignment with the wet side, and gently slide it over until the magnetic field catches.
- Verify the Exterior Pad is Completely Dry Before Placement. Before placing your new dry magnet against the outside of your aquarium, double-check that the soft rubber contact pad is free of any water drops or moisture. If salt water gets trapped between the tight rubber pad and the exterior glass, it will eventually dry out and leave behind rough salt crystals. As you slide the pump around to adjust your flow angles later on, those hard crystals can trap debris and leave permanent scratches on your glass.
- Clean Your Dry Side Padding with a Soft Dry Cloth Only. If your external backing magnet accumulates dust or lint from your aquarium cabinet, wipe it down using a dry microfiber cloth or a blast of compressed air. Avoid spraying the rubber pad with household glass cleaners, chemical detergents, or rubbing alcohol. Harsh chemicals can break down and dry out the specialized rubber compound, causing it to lose its high-friction grip and crack over time.
